Product Description

Overview of Hastelloy C276 Plate

Hastelloy C276 ASTM Standard B575 Plate is a nickel-molybdenum-chromium superalloy with an enhancement of tungsten made to have superb deterioration resistance in a wide variety of extreme atmospheres. Although there are a number of variations of the nickel alloy, Hastelloy C276 Plate is without a doubt the most commonly used.

Like many other nickel alloys, it is pliable, easily developed and also welded. ASTM B575 UNS N10276 Hastelloy C276 Sheet is frequently utilized in several industries, including petrochemical, chemical oil and gas, power generation, pharmaceutical, pulp and paper manufacturing and drainage treatment.

ASME SB 575 UNS N10276 material likewise displays resistance to deterioration by salt water in crevice conditions, which can generate hostile attack in other commonly utilized materials. While sheet steel is less than 3 mm thick, plate steel is certainly thicker than 3 mm.

Hastelloy C276 Main Characteristics

Excellent corrosion resistance in reducing environments.
Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides.
High nickel and molybdenum contents providing good corrosion resistance.
Low carbon content which minimizes grain-boundary carbide precipitation during welding.
Resistance to localized corrosion such as pitting and stress-corrosion cracking.
Withstands corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide.

Mechanical Properties of Hastelloy Alloy Sheets & Plates

Grade	Tensile (ksi)	2% Yield (ksi)	Elongation %	Hardness (HRb)
C22	115	55	60	59
C276	110	52.6	62	/

Chemical Composition

Grade	C	Mn	Si	Co	Ni	Cr	Fe	Mo
Hastelloy C22	0.010 max	0.50 max	0.08 max	2.50 max	50.015 max	20.0-22.5	2.0-6.0	12.5-14.5
Hastelloy C276	0.01 max	1.0 max	0.08 max	Balance	14.5-16.5	4-7	15-17	0.04 max

Weight Per Square Meter (Sheets & Plates)

Size (mm)	Weight per Sheet (Kg)	Size (mm)	Weight per Sheet (Kg)
2000x1000x0.7	11.5	2500x1250x1.5	38.4
2500x1250x0.7	17.9	3000x1500x1.5	55.3
2000x1000x0.9	14.7	2000x1000x2.0	32.7
2500x1250x0.9	23.0	2500x1250x2.0	51.2
2000x1000x1.0	16.4	3000x1500x2.0	73.7
2500x1250x1.0	25.6	2000x1000x2.5	40.9

Frequently Asked Questions

What is the primary advantage of using Hastelloy C276?

The main advantage is its exceptional corrosion resistance in a wide range of aggressive media, including reducing and oxidizing environments, as well as localized corrosion like pitting.

What is the difference between C276 sheet and plate?

The primary difference is the thickness. Sheet steel is typically less than 3 mm thick, while plate steel is thicker than 3 mm.

Can Hastelloy C276 be welded easily?

Yes, Hastelloy C276 is designed to be easily formed and welded. Its low carbon content minimizes carbide precipitation during welding to maintain corrosion resistance in heat-affected zones.

What industries commonly use ASTM B575 UNS N10276?

It is widely used in petrochemical, chemical processing, oil and gas, power generation, pharmaceuticals, and pulp and paper manufacturing.

Does Hastelloy C276 resist salt water corrosion?

Yes, it displays excellent resistance to deterioration by salt water, even in crevice conditions where many other materials fail.

Is Hastelloy C276 resistant to wet chlorine gas?

Yes, it is one of the few materials that can withstand the corrosive effects of wet chlorine gas, hypochlorite, and chlorine dioxide.
