| Category | Details |
|---|---|
| Standard | ASTM A276, A484, A479, A580, A582, JIS G4303, JIS G4311, DIN 1654-5, DIN 17440, KS D3706, GB/T 1220 |
| Material Grade | EN1.4307, EN1.4845, EN1.4547, EN1.4404, EN1.4919, EN1.4571, EN1.4438, EN1.4541, EN1.4878, EN1.4550, EN1.3974, EN1.4511, EN1.4006 |
| Surface Finish | Pickled, Peeled, Black, Sand Blast, Bright etc. |
| Technology | Hot Rolled, Cutting |
| Specifications | 20*3mm - 100*10mm or custom size |
| Tolerance | Standard or as per requirement |
| Size (mm) | Weight (Kg/m) | Size (mm) | Weight (Kg/m) |
|---|---|---|---|
| 12 x 3 | 0.28 | 50 x 6 | 2.37 |
| 20 x 3 | 0.47 | 60 x 6 | 2.84 |
| 25 x 3 | 0.59 | 75 x 6 | 3.56 |
| 30 x 3 | 0.71 | 100 x 6 | 4.74 |
| 40 x 3 | 0.95 | 25 x 8 | 1.58 |
| 50 x 3 | 1.19 | 30 x 8 | 1.9 |
| 60 x 3 | 1.42 | 40 x 8 | 2.53 |
| 75 x 3 | 1.78 | 50 x 8 | 3.16 |
| 100 x 3 | 2.37 | 60 x 8 | 3.79 |
| 12 x 5 | 0.47 | 75 x 8 | 4.74 |
| 20 x 5 | 0.79 | 100 x 8 | 6.32 |
| 25 x 5 | 0.99 | 25 x 10 | 1.98 |
| 30 x 5 | 1.19 | 30 x 10 | 2.37 |
| 40 x 5 | 1.58 | 40 x 10 | 3.16 |
| 45 x 5 | 1.78 | 50 x 10 | 3.95 |
| 50 x 5 | 1.98 | 60 x 10 | 4.74 |
| 60 x 5 | 2.37 | 75 x 10 | 5.93 |
| 75 x 5 | 2.96 | 100 x 10 | 7.9 |
| 100 x 5 | 3.95 | 25 x 12 | 2.37 |
| 12 x 6 | 0.57 | 30 x 12 | 2.84 |
